Bulgin Superflash® Simax 8 High Flow Oxygen Gas Flashback Arrestor 1" NPT Female

The Bulgin DEMAX 5 is a robust, high-flow multi-function fuel flashback arrestor designed for safe connection at cylinder regulators and tapping points. Manufactured in Germany and compliant with DIN EN ISO 5175-1 and AS 4603, this device combines gas non-return, flame arrestor, temperature-sensitive cut-off, and dust filter functions into a compact, serviceable unit to protect personnel and equipment in industrial gas systems. 100% factory tested for safety and performance.

APPLICATIONS

• Cylinder regulator connections

• Tapping points

• Industrial welding

• Cutting operations

• Heating applications

• Fuel gas systems

SPECIFICATIONS

• Product Type: Fuel Flashback Arrestor

• Material: Brass (2.0401) with Spring Steel (1.4310)

• Connection: 1" NPT RH Female

• Max Hose ID: 25 mm

• Cracking Pressure: 50–70 mbar (position-independent)

• Operating Temperature: –20 °C to +60 °C

• Dimensions: Ø 64 mm × 111 mm

• Weight: ~1.27 kg

• Gas Compatibility: Acetylene, Hydrogen, Natural Gas (Methane), Propane

• Function: Gas non-return, flame arrestor, temperature cut-off, dust filtration
