Bulgin GRS50 Gas Flashback Arrestor Brass 1 1/2" (40mm) BSP Female

The Bulgin GRS50 Gas Flashback Arrestor is an industrial gas safety device designed for the protection of ring lines, tapping points, and points of use. This unit provides reliable pressure-related safety functionality but is not flashback resistant, making it suitable for applications where flame arresting is not required. Engineered for stable operation with position-independent low cracking pressure, it supports a wide range of fuel, oxidising, and inert gases in industrial gas distribution systems.

APPLICATIONS

• Safety device for ring lines and points of use

• Town gas, grid gas, natural gas, LPG, cleaned biogas systems

• Suitable for oxygen, combustible gases, and inert gases

• Controlled gas distribution applications requiring reliable pressure-related safety

SPECIFICATIONS

• Nominal diameter: DN 20

• Inlet / Outlet: G 1/2" RH Female (DIN ISO 228)

• Cracking pressure: 4–8 mbar (position-independent)

• Working pressure: Up to 25 bar

• Inlet filter: 100 μm

• Temperature range: –20 °C to +70 °C

• Materials: Brass & Aluminium Alloy
